Titanium Pipes Manufacturer, Supplier and Exporter in Kolkata, India

Ojas Pipes and Tubes, one of the most distinguished manufacturers and suppliers from Kolkata, India, is known for offering superior piping solutions, such as high-performance Titanium Pipes. The pipes are highly prized for their superior strength-to-weight ratio, corrosion–resistance, and durability, and are thus perfectly suitable for various industrial applications. Driven by a keen emphasis on precision, quality, and global standards compliance, Ojas exports Titanium Pipes customized to suit individual industrial requirements. Renowned for their reliability and innovative nature, the firm caters to an extensive sector of industries with superior solutions in very critical and demanding environments.

ASTM B861 Grade 2 Pipe Price In India, Gr 5 Titanium Pipe supplier in United kingdom, Titanium pipe Manufacturers In Kolkata, ASTM B861 Pipe In Kolkata, Titanium Grade 5 Pipe In India, Titanium Round Pipe In Kolkata, Titanium Pipes Manufacturer In India.

Composition and Mechanical Properties of Titanium Pipes
Titanium Pipes consist mainly of pure titanium or titanium alloys with trace quantities of elements like aluminum, vanadium, or palladium to improve certain properties. They have very good mechanical properties, such as a tensile strength varying from 345 MPa to more than 900 MPa based on the grade, and elongation up to 20-30%. Strong but light in weight, Titanium Pipes have very good corrosion resistance, particularly in seawater and chemically aggressive media, as well as improved thermal and electric conductivity.

Titanium Pipes Specification

Titanium Pipe International Specification	ASTM B337 ASME SB337 / ASTM B861 ASME SB861 NACE MRO 175-94, VdTÜV 230/2
Dimensional tolerances	DIN 17861 D3/T3 or closer
Standard Specification	ASME, ASTM, AISI, AMS, JIS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB
Titanium Seamless Pipe Size	OD: 4 to 219mm Wall Thickness: 0.5 to 20mm
Grade 2 Titanium Welded Pipe Size	OD: 5.0 – 1219.2 mm
Titanium Grade 5 EFW Pipe Size	OD: 5.0 – 1219.2 mm
Titanium Grade 2 Pipe WT	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Grade 5 Titanium Pipe manufacturing techniques	Seamless / ERW / EFW/ Welded / Fabricated / CDW/ LSAW/ Seam-Welded / Redrawn
Origin of ASTM B861 Titanium Alloy pipe material	Indian, European, Korean, Japanese
Titanium Metal Gr 5 Pipe End Types	BE : Beveled end BBE : Bevel both ends BLE : Bevel large end BSE : Bevel small end TOE / POE = Treaded One End / Plain One End TOE / BOE = Treaded One End / Beveled One End POE / BOE = Plain One End / Beveled One End TBE = Treaded Both Ends PBE = Plain Both Ends
Form	Round, Square, Rectangular
Ti Metal Gr 2 Pipe Length	Single Random, Double Random & Required Length End: Plain End, Beveled End, Treaded
Titanium Cp Grade 5 Pipe Delivery Condition	Annealed and Pickled, Hot Finished, Polished, Bright Annealed, Cold Drawn
Ti-6AL-4V ELI Titanium Pipe Packing	Ply Wooden Boxes PE Fabric Bundles Steel Strips Bundled Standard seaworthy export packing Plastic Bags, or as required
CP Titanium Pipe Value Added Services	Cut to size, thread, and groove
Port	Mumbai, India
Stocking distributor of leading Titanium Pipe manufacturers	Nippon Steel Corporation, Japan make Titanium Grade 5 Pipe Sumitomo Metals, Japan make Ti Alloy Cp Grade 2 Pipes Sanyo Special Steel, Japan make Titanium Pipe Schoeller Bleckmann, Austria make Grade 2 Titanium Seamless Pipe Seah Steel Corporation, Korea make Titanium Grade 2 Seamless Pipe Kobe Special Tube, Japan make Grade 5 Titanium Pipe Tubacex Tubos Inoxidables S.A., Spain make ASTM B861 Titanium Alloy Pipe
CP Titanium Pipe Dimensional Specification	ANSI/ ASME B36.10, B36.19, B2.1
Marking on Ti-6al-4v Titanium Pipe	Specification Material Grade Nominal Size Schedule or Wall Thickness Method of Manufacturing (Seamless or Welded) Heat Number Manufacturer / supplier Name or Custom Logo – on request Marked Pipe Sample: SEAMLESS TITANIUM PIPE ASTM B861 GR2 SCH 40S OD 48 X WT 0.6MM HEAT NO. XXXX Do not forget to compare our price with other Titanium pipe manufacturers in India

Titanium Pipes Chemical Composition

Titanium Gr 2	C	Ti	N	Fe	H	O	V	Al
Titanium Gr 2	0.1 max	99.2 min	0.03 max	0.3 max	0.015 max	0.25 max	–	–

Titanium Gr 5	C	Ti	N	Fe	H	O	V	Al
Titanium Gr 5	0.10 max	90 min	0.05 max	0.40 max	0.015 max	0.20 max	3.5-4.5	5.5-6.75 max

Titanium Pipes Mechanical Properties

Titanium Alloy	UNS	Proof strength Rp0.2 MPa min	Tensile Stress Rm MPa min	Elongation A % min
Cp Ti Grade 1	R50250	138-310	240	24
Cp Ti Grade 2	R50400	275-450	345	20
Cp Ti Grade 3	R50550	380-550	450	18
Ti Grade 7	R52400	275-450	345	20
Ti Grade 9	R56320	483	620	15
Ti Grade 11	R52250	138-310	240	24
Ti Grade 12	R53400	345	483	18
Ti Grade 16	R52402	275-450	345	20
Ti Grade 17	R52252	138-310	240	24
Ti Grade 26	R52404	275-450	345	20
Ti Grade 28	R52254	483	620	15

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Manufacturer of ASTM B862 Gr 2 Pipe in India, Buy Titanium exhaust pipe in custom length and wall thickness In United kingdom, ASTM B861 Titanium Pipe In Kolkata, Titanium Grade 2 Pipe In Kolkata, Ti-6AL-4V ELI Pipes In India, Ti-6al-4v Titanium Pipe In Kolkata, Ti Alloy Cp Grade 2 Pipe In India.

Why Choose Titanium Pipes from Ojas Pipes and Tubes?

Choosing Titanium Pipes from Brydon Pipes and Tubes ensures exceptional quality, durability, and performance for demanding industrial applications. Our alloy steel pipes are manufactured using high-grade materials that offer superior resistance to corrosion, high pressure, and extreme temperatures. We adhere to stringent quality control standards to guarantee reliable performance in critical sectors such as oil and gas, power generation, and construction. With a commitment to customer satisfaction, Ojas Pipes and Tubes provides tailored solutions, timely delivery, and expert support, making us a trusted partner for all your alloy steel pipe needs.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Titanium Pipes Supplier in Kolkata, India

Ojas Pipes and Tubes, one of the largest suppliers of Titanium Pipes in Kolkata, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

ASTM B861 Grade 2 Pipe Price In India, Gr 5 Titanium Pipe supplier in United kingdom, Titanium pipe Manufacturers In Kolkata, ASTM B861 Pipe In Kolkata, Titanium Grade 5 Pipe In India, Titanium Round Pipe In Kolkata, Titanium Pipes Manufacturer In India.

Types of Titanium Pipes

Are Custom Sizes Available for Titanium Pipes?

Yes, we offer custom sizes for Titanium Pipes to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.

Manufacturer of ASTM B862 Gr 2 Pipe in India, Buy Titanium exhaust pipe in custom length and wall thickness In United kingdom, ASTM B861 Titanium Pipe In Kolkata, Titanium Grade 2 Pipe In Kolkata, Ti-6AL-4V ELI Pipes In India, Ti-6al-4v Titanium Pipe In Kolkata, Ti Alloy Cp Grade 2 Pipe In India.

Titanium Pipes have vast applications in various industries like aerospace, marine, chemical processing, and power generation owing to their corrosion resistance, strength, and longevity. They are suitable for use in heat exchangers, condenser circuits, and piping in offshore facilities and desalination plants. Titanium Pipes are used in the healthcare industry for implants and surgical instruments because they are biocompatible. Further, they are used in automobile and aerospace parts and construction and architecture applications, where light weight but strong materials are required.
