Ojas Pipes and Tubes is a well-established producer and exporter from Kolkata, India, with expertise in producing superior quality Titanium Grade 5 Tubing. With a passion for precision engineering and high-quality raw material inputs, the organization provides long-lasting and high-performance tubing solutions for various industrial processes. Titanium Gr 5, or Ti-6Al-4V, is extensively used for its high strength, corrosion resistance, and lightness of weight. Ojas Pipes and Tubes is dedicated to timely delivery, quality, and customer satisfaction, and as such, it is a reputable name among metal tubes globally and locally.
Titanium Grade 5 Tubing (Ti-6Al-4V) contains about 90% titanium, 6% aluminum, and 4% vanadium. It has high strength-to-weight ratio, with tensile strength of about 950 MPa and yield strength of 880 MPa. Its elongation is around 14%, and it has a hardness of around 36 HRC. Titanium Gr 5 possesses better corrosion resistance, especially in chemical and marine environments, and has mechanical strength at high temperatures up to 400°C, which makes it suitable for harsh structural and industrial applications.
Specification : ASTM B861, B338, B388, B862 / ASME SB861, SB338, SB388, SB862
Pipe Range : ½”NB to 24”NB / SCH 10 – SCH XXS
Tubes Range: 1mm OD to 254mm OD / Thickness 0.1 to 20mm.
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
| Al | Fe | O | Ti | V |
|---|---|---|---|---|
| max | max | max | max | max |
| 6 | 0.25 | 0.2 | 90 | 4 |
| Hardness, Brinell | 334 | 334 | Estimated from Rockwell C. |
|---|---|---|---|
| Hardness, Knoop | 363 | 363 | Estimated from Rockwell C. |
| Hardness, Rockwell C | 36 | 36 | |
| Hardness, Vickers | 349 | 349 | Estimated from Rockwell C. |
| Tensile Strength, Ultimate | 950 MPa | 138000 psi | |
| Tensile Strength, Yield | 880 MPa | 128000 psi | |
| Elongation at Break | 14 % | 14 % | |
| Reduction of Area | 36 % | 36 % | |
| Modulus of Elasticity | 113.8 GPa | 16500 ksi | |
| Compressive Yield Strength | 970 MPa | 141000 psi | |
| Notched Tensile Strength | 1450 MPa | 210000 psi | Kt (stress concentration factor) = 6.7 |
| Ultimate Bearing Strength | 1860 MPa | 270000 psi | e/D = 2 |
| Bearing Yield Strength | 1480 MPa | 215000 psi | e/D = 2 |
| Poisson’s Ratio | 0.342 | 0.342 | |
| Charpy Impact | 17 J | 12.5 ft-lb | V-notch |
| Fatigue Strength | 240 MPa | 34800 psi | at 1E+7 cycles. Kt (stress concentration factor) = 3.3 |
| Fatigue Strength | 510 MPa | 74000 psi | Unnotched 10,000,000 Cycles |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Gr 5 Tubing from Ojas Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Ojas Pipes and Tubes, a leading supplier of Titanium Gr 5 Tubing in Kolkata, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Ojas Pipes and Tubes, we provide custom sizes of Titanium Gr 5 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
Titanium Grade 5 Tubing is extensively used in different industries owing to its strength, corrosion resistance, and lightness. In the aerospace industry, it is utilized in aircraft hydraulic systems, airframes, and engine components. In the medical industry, it is found in surgical equipment and implants. The tubing is also utilized in marine industry uses, oil and gas exploration, power generation, and chemical processing plants. Its resistance to harsh environments qualifies it for high-performance motorsport and defense use. Titanium Gr 5 Tubing is also popular in the automotive sector for exhaust applications and structural parts in prestige automobiles.
