Ojas Pipes and Tubes is a premier producer and exporter of Titanium Grade 2 Tubing from Kolkata, India. It is well known for precision engineering and unflinching quality and provides high-performance tubing solutions for various industrial applications. Focusing extensively on customer satisfaction and international quality standards, Ojas Pipes and Tubes provides corrosion-resistant, lightweight, and reliable titanium tubing suitable for challenging applications. Their modern production center and experienced staff guarantee punctual delivery and quality consistency, making them a reliable partner for customers in aerospace, chemical processing, marine, and medical markets.
Commercially pure titanium (UNS R50400) tubing, known as Titanium Grade 2, contains about 99.2% titanium and minor amounts of iron (0.3%), oxygen (0.25%), carbon (0.08%), nitrogen (0.03%), hydrogen (0.015%). It provides superior corrosion resistance, especially against oxidizing conditions. The mechanical properties are tensile strength of 344 MPa (50 ksi), yield strength of 275 MPa (40 ksi), elongation of 20%, and density of 4.51 g/cm³. Its strength of a moderate nature, high ductility, and good weldability make it suitable for heavy-duty applications involving durability as well as performance.
Specification : ASTM B861, B338, B388, B862 / ASME SB861, SB338, SB388, SB862
Pipe Range : ½”NB to 24”NB / SCH 10 – SCH XXS
Tubes Range: 1mm OD to 254mm OD / Thickness 0.1 to 20mm.
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
| C | Fe | H | N | O | Ti |
|---|---|---|---|---|---|
| max | max | max | max | max | max |
| 0.1 | 0.3 | 0.015 | 0.03 | 0.25 | 99.2 |
| Hardness, Knoop | 170 | 170 | |
|---|---|---|---|
| Hardness, Rockwell B | 80 | 80 | |
| Hardness, Vickers | 145 | 145 | |
| Tensile Strength, Ultimate | 344 MPa | 49900 psi | |
| Tensile Strength, Yield | 275 – 410 MPa | 39900 – 59500 psi | |
| Elongation at Break | 20 % | 20 % | |
| Reduction of Area | 35 % | 35 % | |
| Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
| Compressive Modulus | 110 GPa | 16000 ksi | |
| Poisson’s Ratio | 0.37 | 0.37 | |
| Izod Impact | 114 – 171 J | 84.1 – 126 ft-lb | |
| Fatigue Strength | 300 MPa | 43500 psi | 1E+7 cycles, Unnotched |
| Fatigue Strength | 425 MPa | 61600 psi | 30,000 cycles, Unnotched |
| Fracture Toughness | 66 MPa-m½ | 60.1 ksi-in½ | K(Q); annealed |
| Shear Modulus | 45 GPa | 6530 ksi |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Gr 2 Tubing from Ojas Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Ojas Pipes and Tubes, a leading supplier of Titanium Gr 2 Tubing in Kolkata, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Ojas Pipes and Tubes, we provide custom sizes of Titanium Gr 2 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
Titanium Grade 2 tubing is utilized extensively in most industries because of its high corrosion resistance, lightweight condition, and high strength-to-weight ratio. In the aerospace industry, it is applied in fuel and hydraulic systems. In the chemical processing industry, it is depended upon for piping, reactors, and heat exchangers due to its capability of resisting corrosive chemicals. In marine usage, it performs admirably in seawater cooling and desalination facilities. It is also applied to medical devices, surgical equipment, and implants. Also, Titanium Gr 2 tubing is used in power generation, automobile, and architecture applications for its durability and minimal maintenance requirements.
