Home > Stainless Steel > Stainless Steel Condenser Tubing
Ojas Pipes and Tubes, a well-respected manufacturer and supplier based in Kolkata, India, focuses on providing high-quality Stainless Steel Coil Tubing for a variety of industrial uses. With a reputation for precision manufacturing and strict adherence to international standards, Ojas offers coil tubing solutions that boast exceptional durability, flexibility, and resistance to corrosion. Their stainless steel coil tubing is specifically designed to withstand high pressure, temperature, and harsh environments, making it perfect for critical operations in the oil & gas, chemical, petrochemical, and power sectors. Ojas Pipes and Tubes is dedicated to delivering reliable, cost-effective, and customizable tubing solutions tailored to meet each client’s unique needs.
Stainless Steel Coil Tubing is generally made from stainless steel grades like SS 304, SS 316, or SS 321, containing approximately 18–20% chromium, 8–12% nickel, and low carbon. This blend provides excellent corrosion resistance, impressive mechanical strength, and remarkable flexibility. The tubing boasts a tensile strength of around 515 MPa, yield strength of about 205 MPa, and an elongation of roughly 40%, making it well-suited for high-pressure and high-temperature applications. Ojas ensures precise dimensions, consistent wall thickness, and thorough testing on every coil, delivering products that perform reliably even in demanding operational conditions.
| Specifications | ASTM A213, ASTM A249, ASTM A269 |
| Size Range | 6 mm OD to 219.1 mm OD |
| Outside Diameter | From 6mm~2500mm |
| Length | 1 Mtr Upto 32 Mtrs Long / U-Tube Length – 32 Mtrs U Tube Coil – 50 Mtrs |
| Thickness | 0.7 mm Thick To12.7 mm Thick |
| Form | Seamless, Welded, Hot Rolled, Cold Drawn |
| Shapes | Straight tube, Coil tubing |
| Ends | Plain end, Bevelled end |
| Grades | TP – 304,304L,316,316L,201 |
| STAINLESS STEEL Condenser TUBE GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel Condenser Tubing from Ojas Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Tube is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Ojas Pipes and Tubes, one of the largest suppliers of Stainless Steel Condenser Tubing in Kolkata, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| 12.70 mm OD | x | 0.6 mm wall | in lengths up to 20 m (65.62 ft) |
| 15.00 mm OD | x | 1.22 mm wall | in lengths up to 20 m (65.62 ft) |
| 19.05 mm OD | x | 1.65 mm wall | in lengths up to 20 m (65.62 ft) |
| 25.40 mm OD | x | 2.11 mm wall | in lengths up to 20 m (65.62 ft) |
| 38.10 mm OD | x | 2.64 mm wall | in lengths up to 20 m (65.62 ft) |
Yes, we offer custom sizes for Stainless Steel Condenser Tubing to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.
Stainless Steel Coil Tubing finds extensive use in industries such as oil & gas, chemical processing, geothermal energy, and power generation. It’s perfect for hydraulic control lines, chemical injection systems, instrumentation, heat exchangers, and condensers. The continuous length of coil tubing reduces potential leak points and boosts system efficiency, particularly in offshore platforms, subsea systems, and high-pressure fluid transfer lines. Its flexibility makes it easy to navigate in tight spaces, ultimately lowering installation costs and enhancing overall performance.
