Stainless Steel 347H Pipes

Home > Stainless Steel >Stainless Steel 347H Pipes

Stainless Steel 347H Pipes Manufacturer, Supplier and Exporter in Kolkata, India

A reputable manufacturer and supplier in Delhi, India, Ojas Pipes and Tubes is well-known for providing premium stainless steel 347H pipes made for high-pressure and elevated temperature service. With a higher carbon content, these pipes are an improved form of grade 347 that provide increased strength and resistance to creep. Ojas manufactures these pipes in accordance with global standards and uses strict quality control to guarantee exceptional performance. Ojas Pipes and Tubes is a reliable partner for long-lasting, heat-resistant stainless steel piping solutions in India and overseas, serving sectors like petrochemical, power generation, and oil and gas.

347H Stainless Steel Pipes Exporter in India, SS UNS S34709 Pipes Supplier in India, 347H Stainless Steel Pipe Manufacturer in Kolkata, SUS 347H Pipes Price List in Kolkata, ASTM A312 Stainless Steel 347H Pipe Distributor in Kolkata, Stainless Steel 1.4961 Pipes in India, Stainless Steel TP347H Pipe Exporters in India

Chromium (17–20%), nickel (9–13%), and carbon (0.04–0.10%) make up stainless steel 347H pipes. Columbium and tantalum are added for stability. A higher carbon content to enhance creep resistance and high-temperature strength is indicated by the “H” designation. These pipes have an approximate elongation of 40%, a yield strength of 205 MPa, and a tensile strength of 515 MPa. They are perfect for applications requiring frequent or continuous exposure to high temperatures due to their exceptional resistance to oxidation and intergranular corrosion. 347H’s usability in demanding industrial settings is improved by its mechanical stability and weldability.

Stainless Steel 347H Pipes Specification

Pipe Standard	ASTM A312 ASME SA312 / ASTM A358 ASME SA358
Pipe Dimension	ANSI/ASME B36.19M, ANSI/ASME B36.10M
Pipe Sizes	1 / 2″ NB – 24″ NB
Pipe Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Steel Pipe Manufacturing Process	Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded
Stainless Steel Pipe Shapes	Hydraulic, Round, Rectangle, Square, Hex, Honed
Stainless Steel Pipe Schedule	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Pipe Ends	Half Hard, Soft, Hard, Quarter Hard, Spring Hard
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Value Added Services	Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing

347H Stainless Steel Pipes Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Cb	Ni	Fe
SS 347H	0.04 – 0.10	2.0 max	1.0 max	0.045 max	0.030 max	17.00 – 19.00	8xC – 1.10	9.0 -13.0	63.72 min

SS 347H Pipes Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
347H	515	205	40	92	201

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

SS 347H Schedule 40 Pipe Price List in Kolkata, Stainless Steel S34709 Pipes Supplier in India, SS 347H Pipes Price Per Kg, ASTM A312 Stainless Steel 347H Pipe Exporter in Kolkata, AISI 347H Pipes Stockist in Kolkata, 1 inch SS 347H Pipe Price List in India, SS 347H Pipe Weight Chart, SS 347H Schedule 20 Pipe Thickness, 347H Austenitic Stainless Steel Pipe Manufacturers in Kolkata

Why Choose Stainless Steel 347H Pipes from Ojas Pipes and Tubes?

Choosing Stainless Steel 347H Pipes from Ojas Pipes and Tubes ensures you get the high quality products you need. Our pipe is made from premium materials, providing exceptional strength and corrosion resistance. With extensive industry experience, we put customer satisfaction first, and provide expert guidance throughout the selection process. We offer competitive pricing and strict quality control to meet international standards. Additionally, our commitment to on-time delivery ensures that your services are delivered on time. Trust Brydon for reliable, high-performance plumbing solutions that will stand the test of time.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 347H Pipes Supplier in Kolkata, India

Ojas Pipes and Tubes, one of the largest suppliers of Stainless Steel 347H Pipes in Kolkata, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

Stainless Steel 347H Pipes Sizes in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ASME SA 312 TP347H Pipes Kolkata, Stainless Steel 347H Pipes Exporters in Kolkata, 347H Stainless Steel Pipe Manufacturers in Kolkata, SS UNS S34709 Pipes Supplier in Kolkata, SS 347H Schedule 20 Pipe Stockist in in India, SS 347H Pipes Distributor in India, 347H Stainless Steel Pipes in India

Types of Stainless Steel 347H Pipes

Are Custom Sizes Available for Stainless Steel 347H Pipes?

Yes, we offer custom sizes for Stainless Steel 347H Pipes to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.

SS UNS S34709 Pipes Exporters in India, ASME SA 312 TP347H Pipes Kolkata , SUS 347H Pipes Distributor in India, 347H SS Pipes Price Per Kg, 347H Austenitic Stainless Steel Pipe Supplier in Kolkata, SS 347H Pipe Stockist in Kolkata, Stainless Steel 347H Pipes Dealer in Kolkata

The main applications for stainless steel 347H pipes are high-temperature, high-pressure settings where creep resistance and thermal stability are crucial. They are extensively used in power generation systems, heat exchangers, pressure vessels, refinery piping, and petrochemical plants. They are appropriate for welded structures subjected to high temperatures because of their resistance to intergranular corrosion following welding. These pipes are also utilised in aerospace engine parts, exhaust manifolds, and furnace components. In harsh operating conditions, 347H pipes are the go-to option for durable, high-strength piping systems in chemical processing and thermal plants because they deliver dependable performance.
