Home > Stainless Steel > Stainless Steel 321 and 321H Welded Tubing
Kolkata-based Ojas Pipes and Tubes is a reputable manufacturer and exporter of high-quality Stainless Steel 321 and 321H Welded Tubing. With an unwavering focus on quality, Ojas produces welded tubes that excel in performance and adhere to global standards while serving industrial applications of varied nature. Known for excellence in quality, precision engineering, and timely delivery, the company is catering to customers in a host of industries such as petrochemicals, power generation, and heat exchangers. With their state-of-the-art manufacturing plant and skilled workforce, each product is made to meet durability, corrosion resistance, and consistent performance even in high-temperature conditions.
321 and 321H Stainless Steel are titanium-stabilized austenitic stainless steels. Their usual composition is Chromium (17-19%), Nickel (9-12%), and Titanium (not less than 5 times carbon content). 321H has a greater content of carbon for enhanced strength at high temperatures. These grades provide excellent resistance to intergranular corrosion, particularly after welding. Mechanical properties consist of a minimum tensile strength of 515 MPa, minimum yield strength of 205 MPa, and minimum elongation of 40%, which makes them adequate for severe thermal and mechanical conditions.
Welded Tubes Size : 1 / 8″ NB – 24″ NB
Specifications : ASTM A/ASME SA213, A249, A269, A312, A358
Standard : ASTM, ASME and API
Length : Single Random, Double Random & Required Length
Outer Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB
Thickness : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Types : Welded
Form : Round Tubes, Square Tubes, Rectangular Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
End : Plain End, Beveled End, Treaded
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| SS 321H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Stainless Steel 321 and 321H Welded Tubing from Ojas Pipes and Tubes for exceptional corrosion resistance, superior strength and excellent durability. Ideal for a variety of industrial applications it provides outstanding performance in harsh environments. With precision manufacturing and quality assurance, we ensure reliable and durable tubing solutions.
Ojas Pipes and Tubes is the largest supplier of Stainless Steel 317 and 317L Welded Tubing in Kolkata, India. Known for its high-quality products. We offer superior corrosion resistance, strength, and durability. Trusted by industries worldwide they provide reliable precision-engineered tubing for various applications and project needs.
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| SS 321H | 1.4878 | S32109 | SUS 321H | X12CrNiTi18-9 |
Yes, Ojas Pipes and Tubes offer large custom designs for Stainless Steel 321 and 321H Welded Tubing. With design, wall thickness and length. Their adjustable options ensure the tubing meets specific application requirements. This flexibility makes it more efficient and reliable for different industries and environments. For more details, contact us at sales@ojaspipesandtubes.co.in.
Stainless Steel 321 and 321H Welded Tubing finds broad application in those situations that demand outstanding corrosion resistance and heat resistance. Used in a variety of applications ranging from heat exchangers, exhaust manifolds, furnace parts, flametubes, and equipment for high-temperature chemical processing to aerospace engines, food processing, and pharmaceuticals, these tubes excel at thermal cycling and higher temperatures. These tubes also find applications in oil refineries, aerospace engines, food processing, and pharmaceutical industries because of their capacity to retain mechanical properties in extreme conditions. Their resistance to carbide precipitation upon welding ensures weldability and an extended life, particularly in continuous or repeated service in temperatures of up to 900°C.
