Home > Stainless Steel > Stainless Steel 316H Heat Exchanger Tubing
Located in Delhi, India, Ojas Pipes and Tubes is a well-known producer and supplier of stainless steel 316H heat exchanger tubing, offering high-performance tubing solutions designed for environments with high pressure and temperature. The exceptional strength, resistance to corrosion, and longevity of our SS 316H heat exchanger tubes are well known. These tubes’ improved carbon content gives them remarkable mechanical qualities that make them ideal for heat transfer procedures in demanding industries. Ojas is a reliable partner for crucial thermal applications in industries like petrochemical, power generation, marine, and chemical processing because we place a high value on quality, accuracy, and customer satisfaction.
A high-carbon variant of stainless steel 316, 316H heat exchanger tubing has chromium (16–18%), nickel (10–14%), molybdenum (2–3%), and carbon (0.04–0.10%). The added carbon improves creep resistance and strength at high temperatures. Other elements include sulphur (maximum 0.03%), phosphorus (maximum 0.045%), silicon (maximum 1%), and manganese (up to 2%). It has a yield strength of 30,000 psi (205 MPa) and a minimum tensile strength of 75,000 psi (515 MPa). In industrial systems, these tubes perform exceptionally well mechanically and resist corrosion, especially when subjected to extended heat exposure and thermal cycling.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316H |
| C | 0.10 max |
| Mn | 2.0 max |
| Si | 0.75 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 |
| Ni | 10.00 – 14.00 |
| Fe | 68.89 min |
| Element | SS 316H |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316H Heat Exchanger Tubing from Ojas Pipes and Tubes ensures superior quality and reliability. With expertise in precision manufacturing, Ojas Pipes and Tubes provides 316H tubing that offers exceptional strength and corrosion resistance, especially in high-temperature and corrosive environments. Their products meet stringent industry standards, ensuring long-lasting performance in demanding applications. Additionally, Ojas Pipes and Tubes is known for timely deliveries, excellent customer service, and customized solutions, making them a trusted supplier for industries like chemical processing, power generation, and oil and gas.
Ojas Pipes and Tubes, one of the largest suppliers of Stainless Steel 316H Heat Exchanger Tubing in Kolkata, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316H Heat Exchanger Tubing to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| SS 316H | 1.4401 | S31609 | SUS 316H |
Applications needing high mechanical strength and corrosion resistance at high temperatures are best suited for stainless steel 316H heat exchanger tubing. It is frequently found in power plants, refineries, and petrochemical facilities’ heat exchangers, condensers, boilers, and superheaters. Under high-pressure steam and thermal stress, its high carbon content improves durability and creep resistance. Additionally, the tubing is used in chemical processing facilities, pulp and paper industries, and marine systems where regular exposure to corrosive materials occurs. In crucial heat-handling applications, SS 316H tubing is the material of choice because it guarantees effective heat transfer and long-term dependability.
