Home > Nickel Alloy > Nickel Alloy ERW Pipes
Ojas Pipes and Tubes stands out as a leading manufacturer and supplier of Nickel Alloy ERW (Electric Resistance Welded) Pipes based in Kolkata, India. We pride ourselves on delivering top-notch piping solutions tailored for high-performance industrial applications. Our nickel alloy ERW pipes are designed with exceptional corrosion resistance, impressive strength, and long-lasting durability, all crafted to meet rigorous international standards like ASTM B163 and ASTM B165. Each pipe is meticulously welded to ensure precise dimensional accuracy and mechanical integrity, making them perfect for critical applications in chemical processing, power generation, marine engineering, and aerospace industries. At Ojas, we guarantee reliability and a long service life for all your nickel alloy piping needs.
Nickel Alloy ERW Pipes are primarily made up of a high Nickel content (≥65%) along with alloying elements such as Chromium, Molybdenum, Iron, and Copper, depending on the specific grade (like Alloy 400, 625, or 825). These alloys are known for their outstanding resistance to oxidation, corrosion, and high temperatures. In terms of mechanical properties, they boast tensile strength ranging from 450 to 950 MPa, yield strength between 200 and 690 MPa, and elongation values of 30–45%. The ERW welding process guarantees uniform welds with high structural integrity, making them suitable for pressure and high-temperature applications.
| ASTM Specification | Astm B829 ASME SB829 |
|---|---|
| Standard | ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| ASTM B829 Nickel Alloy Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| ASTM B725 Nickel Alloy Welded Pipe Size | 5.0 – 1219.2 mm |
| Nickel-Cobalt Alloys EFW Pipe size | 5.0 – 1219.2 mm |
| Swg & Bwg | 12 Swg., 10 Swg., 16 Swg., 14 Swg., 20 Swg., 18 Swg., |
| Nickel Pipe Schedule | XS, SCH30, SCH40, XXS, SCH80, SCH120, SCH60, SCH140, STD, SCH10, SCH10S, SCH40S, SCH80, SCH20, SCH5, SCH160 |
| Nickel pipe Length | Double Random, Single Random, Standard & Cut length Pipe |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc |
| Form | Nickel are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| Type of Nickel Alloy Pipe | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Nickel |
| Nickel pipe End | Plain End, Beveled End, Treaded Pipe, Screwed ends |
| Marking on Nickel Steel Pipe | All Astm B725 Nickel Alloy Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application of Nickel pipe | Dairy Pipe, Oil Pipe, Gas Pipe, Fluid Pipe, Boiler Pipe for Chemical Industry |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialize in | Large Diameter NickelPipe |
| Nickel pipe manufacturing Technique | Cold drawn, hot drawn, bright annealed, solid solution, hot extruding |
| Nickel pipe Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Heat Treatment Charts, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Nickel HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 Min | 0.15 Max | – | 0.35 Max | 0.1 Max | 0.4 Max | – | 0.01 Max | 0.25 Max | – | |
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 Max | – | 0.35 Max | 0.35 Max | 0.40 Max | – | 0.01 Max | 0.25 Max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Nickel Alloy ERW Pipes from Ojas Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in nickel alloy products ensures you receive a top-tier solution tailored to your needs.
Ojas Pipes and Tubes, one of the largest suppliers of Nickel Alloy ERW Pipes in Kolkata, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for nickel alloy products in the region.
Yes, we offer custom sizes for Nickel Alloy ERW Pipes to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.
Nickel Alloy ERW Pipes find extensive use in the chemical and petrochemical industries, power plants, marine applications, and aerospace sectors, where resistance to harsh chemicals, high temperatures, and mechanical stress is essential. These pipes are commonly utilized in heat exchangers, pressure vessels, fuel handling systems, and hydraulic lines. Their impressive corrosion resistance against acids, alkalis, and seawater makes them particularly well-suited for offshore and marine environments. The ERW manufacturing process ensures excellent weld quality and dimensional accuracy, allowing for their application in critical, high-pressure, and high-temperature piping systems.
