Ojas Pipes and Tubes, a well-respected manufacturer and supplier located in Kolkata, India, specializes in top-notch Monel Boiler Tubing that’s engineered for peak performance in harsh, high-temperature settings. With years of expertise and a commitment to precision engineering, Ojas provides tubing that adheres to strict international standards, making it perfect for thermal and pressure-heavy applications. Renowned for its remarkable resistance to steam, seawater, and acidic conditions, Monel boiler tubing guarantees durability. Ojas caters to clients in the marine, chemical, and power generation industries, delivering reliable, long-lasting, and tailored Monel tubing solutions for essential boiler and heat exchanger systems.
Monel Boiler Tubing is mainly made up of 63% nickel and 30–34% copper, along with small amounts of iron, manganese, silicon, and carbon. This nickel-copper alloy boasts impressive corrosion resistance, especially in acidic and marine settings. Monel tubing offers a tensile strength ranging from 480 to 620 MPa and a yield strength between 170 and 345 MPa, depending on how it’s processed. It maintains excellent mechanical properties over a broad temperature range, provides good ductility, and withstands thermal stress and oxidation. Monel’s strength and ease of welding make it perfect for demanding high-pressure and high-temperature boiler and condenser applications.
| Boiler Tube Standard | ASTM B163, B730 / ASME SB163, SA730 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Monel Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Monel Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| BWG | BWG | BWG | BWG | BWG | BWG | BWG | BWG | ||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | ||
| Outside Diameter | Outside Diameter | 0.508 | 0.711 | 0.889 | 1.245 | 1.651 | 2.108 | 2.769 | 3.404 |
| mm | inch | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | |
| 6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
| 12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
| 15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
| 19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
| 25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Boiler Tubing from Ojas Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our tubing is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Ojas Pipes and Tubes, one of the largest suppliers of Monel Boiler Tubing in Kolkata, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Our extensive inventory and commitment to exceptional service make us the go-to choice for Monel products in the region.
Yes, we offer custom sizes for Monel Boiler Tubing to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.
Monel Boiler Tubing finds extensive use in settings where extreme heat and aggressive substances are common. It’s particularly suited for marine boilers, steam generators, heat exchangers, and condenser systems due to its exceptional resistance to saltwater corrosion and thermal cycling. In the chemical processing and power generation sectors, Monel tubing is utilized in high-temperature boilers that manage acidic and caustic fluids. Its outstanding mechanical strength and resistance to stress corrosion make it an excellent choice for refineries and desalination plants.
