Home > Incoloy > Incoloy Coil Tubing
Ojas Pipes and Tubes stands out as a top-notch manufacturer and supplier of high-quality Incoloy Coil Tubing, proudly based in Kolkata, India. With a focus on delivering high-performance alloy tubing solutions, Ojas specializes in precision-engineered coil tubing crafted from Incoloy grades like 800, 800H, and 825. These tubes are expertly designed to handle extreme temperatures and corrosive environments, making them perfect for applications in oil & gas, power generation, chemical processing, and marine systems. Committed to upholding international quality standards, offering customized dimensions, and ensuring quick delivery, Ojas Pipes and Tubes has earned a solid reputation for reliability, technical know-how, and durable alloy tubing solutions across the globe.
Incoloy Coil Tubing is generally crafted from high-nickel alloys such as Incoloy 800 or 825, which contain about 38–46% Nickel and 19–23% Chromium, along with some Iron, Molybdenum (in 825), and Titanium. These alloys are known for their outstanding resistance to oxidation, carburization, and acid corrosion. The tubing boasts tensile strengths between 500–700 MPa, yield strengths around 200–350 MPa, and elongation rates of up to 30–40%. Incoloy coil tubing maintains its structural integrity even under varying thermal and mechanical stresses, making it an excellent choice for long runs in high-temperature, high-pressure, and chemically aggressive environments.
| Thickness | 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Outer Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| Form | Round Tubes, Square Tubes, Rectangular Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Beveled End, Treaded. |
Properties | Metric | Imperial |
Density | 8.14 g/cm³ | 0.294 lb/in³ |
Melting point | 1385°C | 2525°F |
|
Element |
Content (%) |
|
Nickel, Ni |
38-46 |
|
Iron, Fe |
22 |
|
Chromium, Cr |
19.5-23.5 |
|
Molybdenum, Mo |
2.50-3.50 |
|
Copper, Cu |
1.50-3.0 |
|
Manganese, Mn |
1 |
|
Titanium, Ti |
0.60-1.20 |
|
Silicon, Si |
0.50 |
|
Aluminum, Al |
0.20 |
|
Carbon, C |
0.050 |
|
Sulfur, S |
0.030 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy Coil Tubes from Ojas Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Incoloy solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Ojas Pipes and Tubes, one of the largest suppliers of Incoloy Coil Tubing in the Kolkatas, India. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
|
Properties |
Metric |
Imperial |
|
Tensile strength (annealed) |
690 MPa |
100000 psi |
|
Yield strength (annealed) |
310 MPa |
45000 psi |
|
Elongation at break (annealed prior to test) |
45% |
45% |
|
Properties |
Metric |
Imperial |
|
|
Thermal expansion co-efficient (at 20-100°C/68-212°F) |
14 µm/m°C |
7.78 µin/in°F |
|
|
Thermal conductivity |
11.1 W/mK |
77 BTU in/hr.ft².°F |
|
Yes, we provide custom sizes for Incoloy Coil Tubes to meet your specific requirements. At Ojas Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@ojaspipesandtubes.co.in.
Incoloy Coil Tubing finds its place in a variety of essential applications that demand corrosion resistance and high-temperature stability. In the oil & gas sector, it’s perfect for chemical injection lines, downhole tubing, and control lines. In power generation and chemical processing, it’s utilized in heat exchangers, condenser tubing, and instrumentation systems. Additionally, this tubing is employed in nuclear plants, aerospace systems, and marine engineering due to its ability to withstand acidic and oxidizing conditions. Its continuous coil design minimizes the need for welding and joints, enhancing reliability and efficiency in various applications.
