Ojas Pipes and Tubes stands out as a premier manufacturer and supplier of high-quality Incoloy Instrumentation Tubing, proudly based in Kolkata, India. Renowned for its unwavering dedication to quality and precision, Ojas provides top-notch tubing solutions crafted from superior Incoloy alloys like 800, 800H, and 825. These tubes are meticulously designed for instrumentation and control systems that operate in highly corrosive and high-temperature settings. By adhering to international standards, employing advanced manufacturing techniques, and offering customized sizing options, Ojas caters to essential industries such as petrochemical, power generation, marine, and aerospace. Customers trust Ojas Pipes and Tubes for its reliability, technical expertise, and swift global service.
Incoloy Instrumentation Tubing is generally produced from alloys like Incoloy 800 or 825, which contain around 38–46% Nickel, 19–23% Chromium, along with Iron, Titanium, and Molybdenum (in 825). This unique blend guarantees outstanding resistance to oxidation, carburization, and a variety of corrosive substances. On the mechanical side, the tubing boasts a tensile strength ranging from 500–700 MPa and a yield strength of 200–350 MPa, with impressive elongation capabilities (up to 30%). Incoloy tubing retains its mechanical integrity even under high temperatures and pressures, making it perfect for precision instrumentation and control systems in demanding industrial environments.
| Specifications | ASTM B 622 ASME SB 622 / ASTM B 619 ASME SB 619 |
| Dimensions | ASME, ASTM, and API |
| Size | 15″NB upto 150″NB IN |
| Specialized in | Sizes in Large Diameter |
| Schedule | Schedule 5, 10, 40, STD, 80, 160 |
| Type | ERW / Seamless / Welded / LSAW Pipes / Fabricated |
| Form | Hydraulic, Round, Etc |
| Length | Double Random, Single Random, & Cut Length. |
| End | Beveled End, Plain End, Treaded |
| Hastelloy C276 | Fe | Ni | P | C | Co | Mo | Si | Mn | S | Cr |
| 4 – 7 | Balance | 0.04 max | 0.01 max | 2.5 max | 15 – 17 | 0.08 max | 1.0 max | 0.03 max | 14.5 – 16.5 |
| Density | Yield Properties (0.2%Offset) | Melting Point | Elongational | Tensile Properties |
| 8.89 g/cm3 | Psi – 52,000 , MPa – 355 | 1370 °C (2500 °F) | 40 % | Psi – 1,15,000 , MPa – 790 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Hastelloy C276 Pipes from Ojas Pipes and Tubes for their exceptional corrosion resistance, high strength, and durability. These pipes are ideal for marine, chemical, and offshore applications, offering long-lasting performance and superior reliability.
Ojas Pipes and Tubes is the largest supplier of Hastelloy C276 Pipes in Kolkata, India, providing top-quality, corrosion-resistant pipes and tubing ideal for marine, industrial, and chemical applications, with reliable delivery and excellent customer service.
| STANDARD | WERKSTOFF NR. | UNS | OR | EN | GOST | JIS |
| Hastelloy C276 | 2.4819 | N10276 | ЭП760 | NiMo16Cr15W | ХН65МВУ | NW 0276 |
Yes, custom sizes are available for Hastelloy C276 Pipes to meet specific project requirements. These pipes can be tailored for various industrial applications. For more details, contact us at sales@ojaspipesandtubes.co.in.
| ASTM B622 Hastelloy C276 Pipe OD mm | Pipe WT mm | in. | Sch | Kg/m |
|---|---|---|---|---|
| 13.72 | 1.65 | 1/4 | 10S | 0.50 |
| 13.72 | 2.24 | 1/4 | 40S | 0.64 |
| 13.72 | 3.02 | 1/4 | 80S | 0.81 |
| 17.15 | 1.65 | 3/8 | 10S | 0.64 |
| 17.15 | 2.31 | 3/8 | 40S | 0.86 |
| 17.15 | 3.20 | 3/8 | 80S | 1.12 |
| 21.34 | 2.11 | 1/2 | 10S | 1.02 |
| 21.34 | 2.77 | 1/2 | 40S | 1.29 |
| 21.34 | 3.73 | 1/2 | 80S | 1.65 |
| 26.67 | 2.11 | 3/4 | 10S | 1.30 |
| 26.67 | 2.87 | 3/4 | 40S | 1.71 |
| 26.67 | 3.91 | 3/4 | 80S | 2.23 |
| 33.40 | 2.77 | 1 | 10S | 2.13 |
| 33.40 | 3.38 | 1 | 40S | 2.54 |
| 33.40 | 4.55 | 1 | 80S | 3.29 |
| 33.40 | 6.352) | 1 | 160 | 4.30 |
| 42.16 | 2.77 | 1¼ | 10S | 2.73 |
| 42.16 | 3.56 | 1¼ | 40S | 3.44 |
| 42.16 | 4.85 | 1¼ | 80S | 4.53 |
| 42.16 | 6.352) | 1¼ | 160 | 5.69 |
| 48.26 | 2.77 | 1½ | 10S | 3.16 |
| 48.26 | 3.68 | 1½ | 40S | 4.11 |
| 48.26 | 5.08 | 1½ | 80S | 5.49 |
| 60.33 | 2.77 | 2 | 10S | 3.99 |
| 60.33 | 3.91 | 2 | 40S | 5.52 |
| 60.33 | 5.54 | 2 | 80S | 7.60 |
| 60.33 | 8.742) | 2 | 160 | 11.29 |
| 73.03 | 3.05 | 2½ | 10S | 5.35 |
| 73.03 | 5.16 | 2½ | 40S | 8.77 |
| 73.03 | 7.01 | 2½ | 80S | 11.59 |
| 88.90 | 3.05 | 3 | 10S | 6.56 |
| 88.90 | 5.49 | 3 | 40S | 11.47 |
| 88.90 | 7.62 | 3 | 80S | 15.51 |
| 88.90 | 11.132) | 3 | 160 | 21.67 |
| 101.60 | 3.05 | 3½ | 10S | 7.53 |
| 101.60 | 5.74 | 3½ | 40S | 13.78 |
| 101.60 | 8.08 | 3½ | 80S | 18.92 |
| 114.30 | 3.05 | 4 | 10S | 8.50 |
| 114.30 | 6.02 | 4 | 40S | 16.32 |
| 114.30 | 8.56 | 4 | 80S | 22.67 |
| 114.30 | 13.492) | 4 | 160 | 34.05 |
| 141.30 | 6.55 | 5 | 40S | 22.10 |
| 141.30 | 9.53 | 5 | 80S | 31.44 |
| 141.30 | 15.882) | 5 | 160 | 49.87 |
| 168.28 | 3.4 | 6 | 10S | 14.04 |
| 168.28 | 7.11 | 6 | 40S | 28.69 |
| 168.28 | 10.97 | 6 | 80S | 43.21 |
| 168.28 | 14.27 | 6 | 120 | 54.75 |
| 168.28 | 18.262) | 6 | 160 | 68.59 |
| 219.08 | 8.18 | 8 | 40S | 43.20 |
| 219.08 | 12.7 | 8 | 80S | 65.63 |
| 219.08 | 18.23 | 8 | 120 | 91.30 |
| 219.08 | 23.012) | 8 | 160 | 112.97 |
Incoloy Instrumentation Tubing finds extensive use in critical applications that demand dependable performance in extreme chemical and thermal conditions. It’s particularly well-suited for instrumentation, control, and impulse lines in chemical plants, offshore oil rigs, nuclear and thermal power stations, and marine systems. The tubing guarantees leak-free connections in high-pressure situations, making it ideal for analytical and sampling lines, hydraulic and pneumatic systems, and process monitoring equipment. Its remarkable resistance to oxidation and corrosion ensures longevity and reliability in the toughest environments.
