Home > Copper Nickel > Copper Nickel Boiler Tubing
Ojas Pipes and Tubes, a well-established Kolkata, India-based manufacturer and supplier of high-quality Copper Nickel Boiler Tubing, is known for its precision-engineered products and industry experience. With corrosion-resistant, high-performance tubing solutions well-suited for marine and industrial usage, Ojas is a trusted brand in the piping industry based on a strong commitment to quality, durability, and delivery. Supported by leading-edge manufacturing technology and stringent quality control, Ojas provides Copper Nickel Boiler Tubes to international standards, catering to customers in power generation, shipbuilding, petrochemical, and offshore industries.
Copper Nickel Boiler Tubing consists of 90% copper and 10% nickel with minor additions of manganese and iron to provide corrosion resistance and mechanical strength. The alloy provides superior resistance to seawater and high-temperature conditions. Its mechanical properties are tensile strength of about 310–350 MPa, yield strength of about 130 MPa, and elongation of 30% or higher, depending on grade. These make the tubing structurally sound withstanding pressure and heat, and thus very dependable for critical boiler and condenser applications in marine and industrial processes.
| Boiler Tube Standard | ASTM B552 / ASME SB552 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Cupro Nickel Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Cupro Nickel Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Properties | Imperial | Metric |
|---|---|---|
| Yield strength (depending on temper) | 40000-76000 psi | 276-524 MPa |
| Shear modulus | 6380 ksi | 44.0 GPa |
| Tensile strength | 38000-77000 psi | 262-531 MPa |
| Elongation at break (in 50.8 mm) | 46% | 46% |
| Poisson’s ratio | 0.34 | 0.34 |
| Elastic modulus | 17000 ksi | 117 GPa |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Designation | Chemical Composition % | ||||||||
| Cu | Sn | Al | As | Ni | Fe | Mn | Pb max. | Zn | |
| C70400 | Rem | – | – | – | 4.8-6.2 | 1.3-1.7 | 0.3-0.8 | 0.05 | 1.0max |
| Property |
Metric Units |
Imperial Units |
|---|---|---|
|
Melting Point (Liquidus) |
11,500°C |
21,000°F |
|
Melting Point (Solidus) |
11,000°C |
20,100°F |
|
Density |
8.94 gm/cm³ @ 20°C |
0.323 lb/in³ @ 68°F |
|
Specific Gravity |
8.94 |
8.94 |
|
Coefficient of Thermal Expansion |
17.1 x 10 -6 / °C (20-300°C) |
9.5 x 10 -5 / °F (68-392°F) |
|
Themal Conductivity |
40 W/m. °K @ 20°C |
23 BTU/ft³/ft/hr/°F @ 68°F |
|
Thermal Capacity (Specific Heat) |
380 J/kg. °K @ 20°C |
0.09 BTU/lb/°F @ 68°F |
|
Electrical Conductivity (Annealed) |
5.26 microhm?¹.cm?¹ @ 20°C |
9.1% IACS |
|
Electrical Resistivity (Annealed) |
0.190 microhm.cm @ 20°C |
130 ohms (circ mil/ft) @ 68°F |
|
Modulus of Elasticity (tension) |
140 GPa @ 20°C |
20 x 10 6 psi @ 68°F |
|
Modulus of Rigidity (torsion) |
52 GPa @ 20°C |
7.5 x 10 6 psi @ 68°F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Copper Nickel Boiler Tubing from Ojas Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Tube is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Choose Copper Nickel Boiler Tubing from Ojas Pipes and Tubes for its superior seawater corrosion resistance, biofouling protection, and excellent thermal conductivity, making it ideal for marine, industrial, and coastal applications requiring long-lasting performance and reliability.
Yes, we offer custom sizes for Copper Nickel Boiler Tubing to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.
Copper Nickel Boiler Tubing finds extensive applications in industries that require high corrosion resistance and conductivity of heat. Some general uses are marine heat exchangers, shipyards, power boilers used in power plants, condensers, and desalination plants. On naval and merchant ships, these tubes find application in seawater systems because they are resistant to stress corrosion and biofouling. They also find application in petrochemical complexes and refineries, particularly where high pressure and high temperature conditions exist. Their high service life, minimal maintenance needs, and compatibility with harsh operating environments make them the choice of priority for critical thermal transfer and fluid systems.
