Carbon Steel DIN 1630 Pipes

Home > Carbon Steel > Carbon Steel DIN 1630 Pipes

Carbon Steel DIN 1630 Pipes Manufacturer, Supplier and Exporter in Kolkata, India

Ojas Pipes and Tubes, Kolkata, India, is a well-known manufacturer and supplier of Carbon Steel DIN 1630 Pipes. They are renowned for their high performance, strength, and durability. These pipes are manufactured utilizing the latest technology and rigorous quality checks to achieve international standards. The company caters to various industries by providing efficient piping solutions as per varied requirements. With emphasis on quality control, prompt delivery, and customer satisfaction, Ojas has emerged as a first choice for carbon steel pipes in both domestic and overseas markets.

1630 Carbon Steel Thin Wall Pipe Supplier in Kolkata, ASME A210 DIN 1630 Pipe Exporter in India, DIN 1630 Carbon Steel Pipe Sizes in mm, DIN 1630 Carbon Steel Pipe Manufacturer in Kolkata, Carbon Steel DIN 1630 Pipes Price List in Kolkata, Large Diameter DIN 1630 Carbon Steel Pipe Distributor in Kolkata, Carbon Steel DIN 1630 Pipes in India, Carbon Steel 1630 Pipes Supplier in Kolkata, DIN 1630 CS Pipes Distributor in India

Carbon Steel DIN 1630 Tubes are composed mainly of carbon (max 0.25%) and manganese (max 1.2%), with small percentages of phosphorus and sulfur (each max 0.025%). The tubes have a minimum yield strength of 235 MPa, tensile strength in the range 360–510 MPa, and elongation of approximately 25%. The composition offers superior mechanical strength, toughness, and weldability to the tubes, which are thus well-suited for high-pressure purposes and allow consistent performance under demanding conditions.

Carbon Steel DIN 1630 Pipes Specification

Standard	ASME A210,JIS G3455,JIS G3456,DIN 1629/3,DIN1629/4
Out Diameter	1/2″-48″(6mm-1240mm)
Wall Thickness	1mm-200mm
Length	5.8-12m ,random length or fixed length
Heat Treatment	Anneal etc
Thecnical	Hot Rolled,Cold Drawn
Package	In Bundling,In Bulk
Suface Treatment	Oil Coating,Black Painted,Varnish,Anti-Corrosion
Payment Terms	T/T,L/C
Application	1>Water Transportation 2>Supply Heat and Gas 3>Long Distance Transport Oil and Natural Gas 4>Agricultural Irrigation 5>Water Conservancy Project

Carbon Steel DIN 1630 Pipes Chemical Composition

Carbon	Silicon	Manganese	Phosphorous	Sulphur	Molybdenum	Nickel	Chromium	Copper	Others
max 0.22	max 0.55	max 1.60	0.04	0.035	–	–	–	–	Al min 0.020

Carbon Steel DIN 1630 Pipes Mechanical Properties

Yield Strength		Tensile Strength			Elongation A5 min
MPa min	ksi min	MPa min	MPa min	ksi min	Percentage
		500	650	–	21

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ANSI B36.19M Carbon Steel DIN 1630 Pipes Exporter in India, Carbon Steel DIN 1630 Pipes Price List in Kolkata, DIN 1630 CS Pipes Supplier in India, Carbon Steel DIN 1630 Pipes Exporter in Kolkata, DIN 1630 Carbon Steel Pipes Exporter in Kolkata, ASME A210 DIN 1630 Pipe Size Chart, Carbon Steel DIN 1630 Pipes Price in India, DIN 1630 Carbon Steel Pipe Weight Chart, Schedule 40 DIN 1630 Carbon Steel Pipe Thickness, DIN 1630 Pipes Supplier in Kolkata, Carbon Steel DIN 1630 Pipes Stockist in India

Why Choose Carbon Steel DIN 1630 Pipes from Ojas Pipes and Tubes?

Choosing Carbon Steel DIN 1630 Pipes from Ojas Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Carbon Steel DIN 1630 Pipes Supplier in Kolkata, India

Ojas Pipes and Tubes is one of the largest Carbon Steel DIN 1630 Pipes suppliers in Kolkata, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.

Carbon Steel DIN 1630 Pipes Dimensions

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ANSI B36.19M Carbon Steel DIN 1630 Pipes Exporter in India, DIN 1630 Carbon Steel Pipe Price List in Kolkata, DIN 1630 CS Pipe Supplier in India, Carbon Steel DIN 1630 Pipes Exporter in Kolkata, Carbon Steel DIN 1630 Pipes Exporter in Kolkata, DIN 1630 Pipes Size Chart, 1630 Carbon Steel Pipe Price in India, DIN 1630 Pipes CS Weight Chart, Carbon Steel DIN 1630 Pipes Thickness, CS DIN 1630 Pipes Supplier in Kolkata, 1630 Carbon Steel Thin Wall Pipe Stockist in India

Types of Carbon Steel DIN 1630 Pipes

Are Custom Sizes Available for Carbon Steel DIN 1630 Pipes?

Yes, we offer custom sizes for Carbon Steel DIN 1630 Pipes to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.

Carbon Steel DIN 1630 Pipes Supplier in Kolkata, 1630 Carbon Steel Thin Wall Pipe Exporter in India, CS DIN 1630 Pipes Manufacturer in Kolkata, Carbon Steel DIN 1630 Pipes Price List in Kolkata, DIN 1630 Pipes Carbon Steel Distributor in Kolkata, 1630 CS Pipes in India, DIN 1630 Pipes Supplier in Kolkata, Carbon Steel DIN 1630 Pipes Distributor in India, CS DIN 1630 Pipe Sizes in mm

Carbon Steel DIN 1630 Pipes are extensively applied in high-pressure operations in industries like oil and gas, petrochemicals, power generation, and construction. They find perfect applications in conveying fluids and gases in critical systems, such as boilers, heat exchangers, hydraulic lines, and structural frames. These pipes are also employed in mechanical and general-purpose applications owing to their long lifespan and stress-resisting property. Their reliability to function well in high temperature and pressure is the reason why they are a preference by engineers and project managers across the globe.
