Home > Carbon Steel > Carbon Steel API 5L Grade X42 Pipes
Ojas Pipes and Tubes, a prominent manufacturing and supplying company from Kolkata, India, excels in the production of top-notch Carbon Steel API 5L Grade X42 Pipes. Their pipes are known for their strength and accuracy in engineering and are made to adhere to high industrial standards while ensuring optimal performance in harsh conditions. Pledging strong support to customers with prompt delivery, Ojas Pipes and Tubes provides dependable solutions for numerous industrial uses. Their proficiency guarantees product quality consistency, positioning them as a reliable partner for companies needing API 5L Grade X42 pipes in India and across the globe.
Carbon Steel API 5L Grade X42 pipes largely contain low carbon content, which is usually between 0.25% to 0.28%, along with manganese, phosphorus, sulfur, and trace elements for improved strength and weldability. Mechanically, the pipes have a minimum yield strength of 42,000 psi, tensile strength of 60,000 to 80,000 psi, and good elongation characteristics, which guarantee toughness and flexibility. The balanced composition has outstanding corrosion resistance and impact toughness, ideal for high-pressure and aggressive environments.
| Mechanical Properties PSL 1 | |||||
| Grade | Yield Strength(Min.) | Tensile Strength(Min.) | Elongation | ||
| Ksi | MPa | Ksi | MPa | E=1944 A 0.2 /U 0.9 | |
| B | 35 | 241 | 60 | 414 | |
| X42 | 42 | 290 | 60 | 414 | |
| X46 | 46 | 317 | 63 | 434 | |
| X52 | 52 | 359 | 66 | 455 | |
| X56 | 56 | 386 | 60 | 414 | |
| X60 | 60 | 414 | 63 | 434 | |
| X65 | 65 | 448 | 66 | 455 | |
| Chemical Composition % | ||||||||
| PSL1 | PSL2 | |||||||
| Grade | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) |
| A | 0.22 | 0.90 | 0.03 | 0.03 | 0.22 | 1.20 | 0.025 | 0.015 |
| B | 0.26 | 1.20 | 0.03 | 0.03 | 0.22 | 1.30 | 0.025 | 0.015 |
| X42 | 0.26 | 1.30 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X46 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X52 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X56 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X60 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.45 | 0.025 | 0.015 |
| X65 | 0.26 | 1.45 | 0.03 | 0.03 | 0.22 | 1.65 | 0.025 | 0.015 |
| X70 | 0.26 | 1.65 | 0.03 | 0.03 | 0.22 | 1.85 | 0.025 | 0.015 |
PSL 2 Pipe Sizes: Nominal Pipe Size 1/2″ to 48 ” O.D.
Wall Thickness: Schedule 10 through 160, STD, XS, XXS.
API 5L PSL 2 Seamless Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450)
DIMENSION: FROM 1/4” UP TO 24”
API 5L PSL 2 Welded Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450) – X70 (L485) – X80 (L555)
DIMENSION: FROM 1/2” UP TO 60”
Weld Alternatives: ERW, HF, DSAW/SAWL, SMLS, HSAW
PSL 2 Pipe Product Specification Level: API 5L PSL 2 PSL 2, API 5L PSL 2 PSL 1
Additional Services: Internal Coating
API 5L Grade B Hot Selling Grades: API 5L X42 Pipe, API 5L X46 Pipe, API 5L X52 Pipe, API 5L X56 Pipe, API 5L X60 Pipe, API 5L X65 Pipe, API 5L X70 Pipe
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel API 5L Grade X42 Pipes from Ojas Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Ojas Pipes and Tubes is one of the largest Carbon Steel API 5L Grade X42 Pipes suppliers in Kolkata, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel API 5L Grade X42 Pipes to meet your specific requirements. Our team at Ojas Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@ojaspipesandtubes.co.in.
API 5L Grade X42 carbon steel pipes are commonly utilized in the oil and gas industry for the transmission of natural gas, crude oil, and water. Their strong structure and superior mechanical properties make them suitable for pipeline systems, such as onshore and offshore applications. They also find good applications in construction, chemical plants, and water transport systems. The pipes are preferred due to their resistance to high-pressure, temperature extremes, and corrosive conditions for secure and efficient fluid transmission in important industrial applications.
