Home > Alloy Steel> ASTM A335 Gr P22 Seamless Pipe
Ojas Pipes and Tubes is a prominent Kolkata, India-based manufacturer and supplier of high-quality ASTM A335 Gr P22 Seamless Pipes. With precision engineering and high-intensity manufacturing processes, Ojas provides superior product durability and performance. Our seamless pipes are strictly in line with industry requirements and are highly regarded for their strength and ability to withstand high temperature and pressure. With a widespread network of distribution all over India, Ojas Pipes and Tubes is dedicated to providing excellence in each pipe, hence becoming the go-to option for industrial purposes demanding ASTM A335 Gr P22 seamless pipes.
ASTM A335 Gr P22 Seamless Pipes contain mainly alloying elements like chromium (2.25%) and molybdenum (1%), which provide strength and resistance against corrosion. Carbon content is usually in the range of 0.05-0.15%, which adds hardness and durability. Mechanically, these pipes provide a tensile strength of around 415 MPa and yield strength of 205 MPa with a minimum elongation of 30%. They have superior high-temperature creep resistance and impact toughness, which makes them suitable for applications in extreme conditions.
| ASTM A335 P22 Size | : | 1/8NB TO 24NB IN |
| ASTM A335 P22 Standards | : | ASTM A 335, ASME SA 335, ANSI B36.10 |
| ASTM A335 P22 Type | : | Seamless |
| ASTM A335 P22 Specialized in | : | Large Diameter Size |
| ASTM A335 P22 Outer Dimensions | : | 19.05 – 114.3mm |
| ASTM A335 P22 Wall Thickness | : | 2.0 – 14 mm |
| ASTM A335 P22 Length | : | max 16000mm |
| ASTM A335 P22 Schedule | : | Schedule 20 – Schedule XXS (heavier on request) up to 250 thk. |
| ASTM A335 P22 Form | : | Round, Square, Rectangular, Hydraulic Etc. |
| ASTM A335 P22 Length | : | Single Random, Double Random & Cut Length. |
| ASTM A335 P22 Tubing End | : | Plain End, Beveled End, Treaded |
| Grade | C % | Mn % | P % | S % | Si % | Cr % | Mo % |
|---|---|---|---|---|---|---|---|
| P22 | 0.05 – 0.15 | 0.30 – 0.60 | 0.025 max | 0.025 max | 0.50 max | 1.90 – 2.60 | 0.87 – 1.13 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % |
|---|---|---|---|
| P22 | 415 min | 205 min | 30 min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing ASTM A335 Gr P22 Seamless Pipe from Ojas Pipes and Tubes ensures superior corrosion resistance, excellent thermal conductivity, high strength, and long-lasting performance. Our commitment to quality and precision makes our pipes and tubing ideal for demanding industrial applications.
Ojas Pipes and Tubes is the largest supplier of ASTM A335 Gr P22 Seamless Pipe in Kolkata, India. We offer premium-quality, corrosion-resistant pipes and tubing ideal for marine, chemical, and industrial applications, with our reliable delivery and customized solutions to meet diverse client needs.
Yes, custom sizes are available for ASTM A335 Gr P22 Seamless Pipe to meet specific requirements. These pipes can be tailored for various industrial applications. For more details, contact us at sales@ojaspipesandtubes.co.in.
ASTM A335 Gr P22 Seamless Pipes are applied in power plants, petrochemical companies, and refineries because they have high-temperature and high-pressure bearing capabilities. They are necessary for superheater tubes, boiler tubes, and heat exchanger tubing. The pipes also have uses in the oil & gas industry and chemical processing industry, where they must be very resistant to thermal stress and durable. Their seamless feature means no weak spots, so they are perfect for safety-sensitive and critical environments.
